Navistar MaxxForce 4.8 & 7.2 Engines Workshop Manual




Navistar MaxxForce 4.8 & 7.2 Engines Workshop Manual
Pages: 244
Format: PDF
Size: 31 MB
Language: English
Requirements: Adobe PDF Reader & WinZip
Compatibility: All Windows, Mac OS, iOS, Android, Linux

To create this Manual it has been taken as base a generic MAXXFORCE 4.8/7.2 engine, which operations and maintenance procedures are the same for all models of this series. The illustrations therefore, could differ from application to application. In this Manual, all references to the components of the engine are divided in 17 specific sections. For your convenience, the organization of the Manual is consistent with MIM Service Bulletins

Manual Covers:

Technical Data
Operation and Maintenance
Engine Block
Pistons and Connecting Rods
Cylinder Heads
Housing Gear
Flywheel and Flywheel Housing
Balancer Unit
Lubrication System
Engine Electrical
Cooling System
Fuel Injection System
Intake, Exhaust and Turbocharger System
Failures Diagnosis
Appendix A
Appendix B
