Type: Compact Excavator
Pages: 678
Format: PDF
File Size: 22 MB
Part Number: CG5E001
Language: English
Compatibility: PC, Mac, tablet, smartphone
This is a digital product. No physical book or CD will be shipped.
Offset trenches along a footing are the diet of a TB138FR, and the swing linkage that makes them possible is what wears quietly. This complete service and repair manual covers the Takeuchi TB138FR compact excavator, book number CG5E001. It runs from general precautions and tightening torques through specifications, machine configuration and the hydraulic units, then into engine coverage shared with the Yanmar 3TNV and 4TNV industrial diesels. Machine configuration takes in the interference prevention system, proportional control and the security system. Troubleshooting splits overall machine, travel, slewing, boom, arm, bucket, offset, dozer blade and auxiliary hydraulics, so a symptom points at a circuit rather than a parts list. A creeping offset cylinder does not need an engine rebuild.
Contents:
I . GENERAL
II . SPECIFICATIONS
III . MACHINE CONFIGURATION
IV . HYDRAULIC UNITS
V . TROUBLESHOOTING
VI . ENGINE
